Delivered Apparatus

FEATURES:

• Spartan Metro Star ELFD 24” Raised Roof Chassis
• Cummins L9 450 HP Diesel Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty Stainless-Steel Body and Subframe
• ROM Roll Up Doors, Satin Finish with Pull Straps
• Cab Exterior Storage Compartments One (1) Each Side
• Two (2) 1000# Transverse Trays with Vertical Tool Board L1/R1 Compartments
• Five (5) 500# Roll Out Trays One (1) Each Compartment L1, L4, R1, R4, Rear
• Two (2) Poly Cribbing Boxes R1 Compartment
• Three (3) 500# Roll Out Drop Down Trays One (1) Each Compartment L2, R2, R4
• One (1) 250# Roll Out Drop Down Trays L4 Compartment
• One (1) Transverse 1000# Tray L2/R2 Compartments
• One (1) Custom Six (6) Drawer Toolbox R2 Compartment
• Air Bottle Rack with Capacity for Fourteen (14) Bottles L2 Compartment
• Four (4) 250# Roll out Trays with Vertical Tool Board Two (2) Each L3, R3 Compartments
• Backboard and Stokes Basket Storage Transverse L3/R3 Compartments
• One (1) Upper Oil Dry Hopper L4 Compartment
• One (1) Vertical Divider L4 Compartment
• One (1) 1000# Roll Out Tray Rear Compartment
• One (1) Air Bag Rack Rear Compartment
• Six (6) Upper Compartments
• One (1) Wheel Chock Compartment Left Side Forward of Wheel Well
• One (1) Hannay Cord Reel Rear Compartment
• One (1) Hannay Air Reel Rear Compartment
• Front and Rear Mounted Trailer Hitch with Tie Off Points One (1) Each Side
• One (1) PTO Driven 25kW Onan Generator
• Rescue Tool Air System R4 Compartment
• Whelen LED Warning Light Package
• Five (5) Whelen Scene Lights, Two (2) Each Side, One (1) Rear
• Night Scan 900W 90,000 Lumen Light Tower
• Whelen LED Arrow Stick
• Aluminum Rub Rails with LED Ground Lights and LED Warning Lights
• Whelen Electric Siren & 100 W Speaker
• 11’ 3” Overall height
• 37’ 8” Overall length
• 236.5” Wheelbase
• 162.5” Cab to Axle
• 21,500 FAWR
• 27,000 RAWR
• 48,500 GVWR
