1500 GPM PUMPER #2534
TOWN OF BROWNVILLE JOINT FIRE DISTRICT - BROWNVILLE, NEW YORK- May 22, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM PUMPER #2534
- Spartan Metro Star EMFD 10” Raised Roof Chassis
- Cummins 400 HP L9 Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless Steel Body and Sub-Frame
- Eight (8) Person Cab
- EMS Cabinet Rear Facing Behind Center Console
- Stainless-Steel Top Mount Pump Module w/ 22” Midship Walkway
- Hale DSD 1500 GPM Single Stage Split-Shaft Pump
- Trident Air Prime System Location
- Two (2) 6” Intakes, One (1) Each Side
- One (1) 6” Front Intake, Electric Valve and Low Level Strainer Preconnect
- One (1) 2½” Gated Intake, Left Side
- Two (2) 2½” Discharges, Left Side
- Two (2) 2½” Discharges, Right Side
- One (1) 3” Discharge, Right Side Adapted to 2½” NST
- One (1) 4” Discharge, Right Side Adapted to 5” Storz
- Two (2) 1½” Mattydale Preconnects
- 21” Extended Front Bumper with One (1) 1½” Front Bumper Preconnect
- 1000 Gallon Poly Tank
- ROM Roll-Up Doors
- One (1) Roll Out Drop Down Tray Each, L1, R1, R2, R3 Compartments [...]
AFE DEMO #2648 – 1250 GPM EQUALIZER PUMPER
Alexis Fire Equipment - Alexis IL- May 20, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on AFE DEMO #2648 – 1250 GPM EQUALIZER PUMPER
- International HV607 Crew Cab Chassis
- Cummins 360 HP L9 Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless Steel Body with Stainless Steel Subframe
- Stainless-Steel Pump Module
- Darley PSM 1250 GPM Split-Shaft Pump
- Trident Air Prime System
- Top Mount Pump Panel with Pistol Grip Controls
- FRC Pump Boss Max Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Each Side
- One (1) 2½” Gated Intake, Left Side
- One (1) 5” Rear Intake
- One (1) Booster Reel – Rear Compartment
- Two (2) 1½” Mattydale Preconnects Mounted in the Walkway
- Two (2) 2½” Discharges, Left Side
- One (1) 2½” Discharge, Right Side
- One (1) 3” Discharge, Right Side Adapted to 5” Storz
- One (1) 3” Discharge Adapted to 2½” NST, Rear
- FoamPro 1600 Class A Foam System with 10 Gallon Tank
- 3” Fixed Monitor Piping Pump Panel Controlled
- 1000-Gallon Poly Tank with Through the Tank Ladder and Suction Hose Storage
- Progressive Dynamics Charger [...]
UTILITY BRUSH TRUCK #S789
LEROY COMMUNITY FIRE PROTECTION DISTRICT - LEROY, ILLINOIS- May 13, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on UTILITY BRUSH TRUCK #S789
- Chevrolet Silverado MD 4×4 Crew Cab Chassis
- 6.6L V8 Turbo-Diesel Engine
- Allison 2700 EVS Automatic Transmission
- Buckstop Replacement Bumper w/ Brush Guard and Receiver
- Heavy Duty Aluminum Treadplate Body and Aluminum Sub-Frame
- Painted Box Doors with LED strip lights
- One (1) Top/Rear Access Compartment, Above Left Compartments
- One (1) Hose Tray, Above Right Compartments
- Waterous PB18-2515-LE Pump
- One (1) 2½” Rear Gated Intake
- Two (2) 1½” Rear Discharges
- One (1) 1” Rear Discharge
- Hannay Booster Reel w/ Chief XD Nozzle, Right Rear Corner of Body
- Akron Model 3462 Front Forestry Turret w/ Cab Joystick Control
- 300-Gallon Poly Tank
- 10 Gallon Foam Tank w/ Scotty Foam Inductor
- Tecniq LED Warning Light Package
- FireTech Scene Light Package
- One (1) Golight Remote Controlled Spotlight, Lightbar Mounted
- Whelen Electronic Siren & 100W Speaker
- Progressive Dynamics Charger w/ Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection
- 8’ 8” Overall Height
- 25’ 10” Overall Length
- 199” Wheelbase
- 84” Cab [...]
TOP CONTROL 1500 GPM EQUALIZER PUMPER #2531
NEW BERLIN – ISLAND GROVE FIRE PROTECTION DISTRICT - NEW BERLIN, ILLINOIS- April 29, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on TOP CONTROL 1500 GPM EQUALIZER PUMPER #2531
- Freightliner M2 106 4-Door Chassis
- 360 HP Cummins L9 Diesel Engine
- Allison 3000 EVS Transmission
- Five (5) Person Cab
- 18” Front Bumper Extension with Center Hose Well
- On Spot Chains
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Top Mount Stainless-Steel Pump Module with 22” Midship Walkway
- Hale DSD Single Stage Split-Shaft 1500 GPM Pump
- Trident Two (2) Location Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Left Side, One (1) Right Side
- One (1) 2½” Gated Intake, Left Side
- One (1) 5” Rear Intake adapted to 6” NST
- One (1) 3” FirePrograms Tank Fill adapted to 2½” NST, Right Side
- One (1) 1½” Front Bumper Preconnect
- Two (2) 2½” Discharges, Left Side
- One (1) 2½” Discharge, Right Side
- One (1) 3” Discharge, Right Side adapted to 5” Storz
- One (1) 3” Discharge, Rear adapted to 2½” NST
- Akron 3423 Deck Gun with 18” Task Force [...]
1500 GPM TOP CONTROL PUMPER #2511
GALESBURG FIRE DEPARTMENT - GALESBURG, ILLINOIS- April 29, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM TOP CONTROL PUMPER #2511
- Spartan FC-94 MFD 10” Raised Roof
- Cummins L9 450 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Four (4) Person Cab
- ROM Painted Roll-Up Doors
- Hale DSD 1500 gpm Pump
- Trident Air Primer, Two (2) Location
- 750 Gallon Poly Tank
- Stainless-Steel Top Mount Pump Module w/ 22” Midship Walkway
- Two (2) 6” Intakes, One Each Side, Left and Right
- One (1) 5” Front Intake
- One (1) 2½” Gated Intake, Left Side
- Three (3) 2½” Discharges, Two (2) Left and One (1) Right Side
- One (1) 3” Discharge Reduced to 2½” MNST, Rear
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- Two (2) 1½” Mattydale Preconnects Deep Cut
- TFT Crossfire XFC-42 Deck Gun with 18” Extend-A-Gun
- Two (2) Free Floating Hose Wells, One Each Left and Right Side Running Boards
- Two (2) Triple Air Bottle Wheel Well Compartments, One (1) Each Side Ahead
- One (1) Fire Extinguisher Wheel [...]
2000 GALLON TANKER #2585
WAREHAM FIRE DEPARTMENT - WAREHAM, MASSACHUSETTS- April 12, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 2000 GALLON TANKER #2585
- Spartan Metro Star MFD 10” Raised Roof
- Cummins 380 HP L9 Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Six (6) Person Cab
- Stainless-Steel Pump Module
- Waterous CXVC20 1250 GPM Pump
- Trident Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Each Left and Right Side
- One (1) 2½” Gated Intake, Left Side
- Two (2) 2½” Discharges, Left Side
- One (1) 2½” Discharge, Right Side
- One (1) 3” Discharge 3” NST Adapted to 5” Storz, Right Side
- Two (2) 1½” and One (1) Deadlay Mattydale Preconnects
- 2000 Gallon Poly Tank
- One (1) 2½” FirePrograms Rear Tank Fill, Left of Dump
- One (1) 10” Newton Stainless-Steel Manual Swivel Dump, Rear
- Four (4) Folding Steps, Rear
- ROM Painted Roll-Up Doors
- Three (3) 250# Roll Out Trays, L1, L3 and R2 Compartments
- PacTrac Rear Wall, L2
- Zico 2,100G Hydraulic Folding Tank Rack Right Side [...]
1500 GPM SIDE CONTROL PUMPER #2490
ELBA SALEM FIRE PROTECTION DISTRICT - YATES CITY, ILLINOIS- April 12, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM SIDE CONTROL PUMPER #2490
- Spartan FC-94 MFD 10” Raised Roof
- Cummins L9 450 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Five (5) Person Cab Seating
- Hale DSD 150 1500 GPM Pump
- Trident Air Primer
- 1000 Gallon Poly Tank
- Stainless-Steel Side Mount Pump Module
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Each Left and Right sides
- Three (3) 2½” Discharges, Two (2) Left and One (1) Right
- One (1) 2½” Discharge, Rear Side Control
- One (1) 3” Discharge 5” MNST, Right Side
- One (1) 2½” Gated Intake, Left Side Control
- Two (2) 1½” and One (1) 2 ½” Mattydale Preconnects
- One (1) 1½” Bumper Extension Preconnect
- Akron 3423 Deck Gun
- Two (2) Triple Air Bottle Wheel Well Compartments, Left and Right Side Ahead
- One (1) Fire Extinguisher Wheel Well Compartment, Right Side Behind
- ROM Roll-Up Doors
- Two (2) Adjustable Shelves, L1 Compartment
- Hinged PacTrac Tool [...]
3,500 GALLON TANKER #2528
SCIPIO TOWNSHIP VOLUNTEER FIRE DEPARTMENT - LAPORTE, INDIANA- April 12, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 3,500 GALLON TANKER #2528
- Freightliner 108 SD Chassis
- Cummins 400 HP L9 Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Two (2) Person Cab
- Stainless-Steel Pump Module
- Darley HM 500 GPM PTO Pump
- Trident Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 4” Intakes, One (1) Each Left and Right Side
- Two (2) Free Floating Hose Wells, One (1) Each Left and Right Side Running Boards
- One (1) 2½” Discharge, Left Side
- One (1) 3” Discharge 3” NST x 5” Storz, Right Side
- Two (2) 1½” and One (1) 2½” Mattydale Preconnects
- Two (2) Single Wheel Well Air Bottle Compartments, One (1) Each Side Ahead of Rear Wheels
- Two (2) SCBA Complete Air Pack Wheel Well Compartments, One (1) Each Side Between Rear Wheels
- ROM Roll-Up Doors
- 3,500 Folding Tank Bracket, Right Side
- 3,500 Gallon Elliptical Stainless Steel Tank
- Two (2) 2½” FirePrograms Rear Tank Fills
- One (1) [...]
1500 GPM MINI PUMPER #2524
DEPOSIT FIRE DEPARTMENT - DEPOSIT, NEW YORK- April 12, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM MINI PUMPER #2524
- Ford F-550 4×4 Super Duty Crew Cab
- 6.7L 4V OHV V8 Turbo Diesel Engine
- TorqShift 10-Speed Automatic Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Hale DSD 1500 GPM Pump
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Each Side
- One (1) 2½” Gated Intake Left Side
- One (1) 5” Rear Intake Adapted to 5” NST
- One (1) 2½” Discharge, Left Side
- One (1) 2½” Discharge, Right Side
- One (1) 3” Discharge, Right Side
- Two (2) 1½” Foam Capable Mattydale Preconnects
- One (1) 2½” Preconnect, Hose Bed Right Side
- Foam Pro 1600 with 20 Gallon Class A Tank
- 300-Gallon Poly Tank
- ROM Painted Roll-Up Doors
- Aluminum Pegboard Rear Wall L2, R2 Compartments
- One (1) Walk-Away Air Pack Bracket L2 Compartment
- One (1) Vertical Pull Out Board, R1 Compartment
- One (1) 500# Roll Out Tray, R3 Compartment
- Ladder Storage Above Right Compartment Tops
- Two (2) Hard Suction and Pike [...]
