1500 GPM PUMPER #2537
TOMBALL FIRE RESCUE, TOMBALL, TEXAS- July 9, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM PUMPER #2537
- Spartan Gladiator LLFD 10” Raised Roof
- Cummins L9 400 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Four (4) Person Cab
- EMS Compartment in Cab Forward Facing Center Rear Wall
- External Chassis Storage Compartments, One (1) Each Side Above Wheel Wells, One (1) Each Side Rearward of Rear Doors
- Side Mount Stainless-Steel Pump Module w/ Black Reflex Coating
- ROM Painted Roll-Up Doors
- MAC1 TAC150 1500 GPM Single Stage Pump
- Trident Automatic Air Primer
- 750 Gallon Poly Tank
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One Each Left and Right Sides
- 24” Extended Front Bumper /w One (1) 2½” Preconnect & Center Hosewell
- Two (2) 1½” Mattydale Preconnects
- Five (5) 2½” Discharges, Two (2) Left Side, One (1) Right Side, Two (2) Rear
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- Akron 3423 Deck Gun with TFT 18” Extend-A-Gun
- Hannay Booster Reel [...]
1500 GPM PUMPER #2536
TOMBALL FIRE RESCUE, TOMBALL, TEXAS- July 9, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM PUMPER #2536
- Spartan Gladiator LLFD 10” Raised Roof
- Cummins L9 400 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Four (4) Person Cab
- EMS Compartment in Cab Forward Facing Center Rear Wall
- External Chassis Storage Compartments, One (1) Each Side Above Wheel Wells, One (1) Each Side Rearward of Rear Doors
- Side Mount Stainless-Steel Pump Module w/ Black Reflex Coating
- ROM Painted Roll-Up Doors
- MAC1 TAC150 1500 GPM Single Stage Pump
- Trident Automatic Air Primer
- 750 Gallon Poly Tank
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One Each Left and Right Sides
- 24” Extended Front Bumper /w One (1) 2½” Preconnect & Center Hosewell
- Two (2) 1½” Mattydale Preconnects
- Five (5) 2½” Discharges, Two (2) Left Side, One (1) Right Side, Two (2) Rear
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- Akron 3423 Deck Gun with TFT 18” Extend-A-Gun
- Hannay Booster Reel [...]
1500 GPM MAP PUMPER #2550
BLOOM TOWNSHIP VOLUNTEER FIRE DEPARTMENT - BLOOMVILLE, OHIO- July 9, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM MAP PUMPER #2550
- Freightliner M2 106 Crew Cab Chassis
- Cummins L9 360 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Aluminum Body and Subframe
- Five (5) Person Cab
- Hale DSD 1500 GPM Split Shaft Pump
- Trident Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- 1,000 Gallon Poly Tank
- Aluminum Top Mount Pump Module w/ 22” Walkway
- Two (2) 6” Intakes, One Each Side, Left and Right
- One (1) 5” NST Electric Front Intake
- One (1) 1½” Bumper Extension Preconnect
- Two (2) 1½” Cartridge Lay Preconnects
- One (1) 2½” Discharge, Left Side
- One (1) 2½” Discharge, Right Side
- One (1) 2½” Discharge, Rear
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- 3” Fixed Monitor Piping Above Module
- 18” Front Bumper Extension with Center Hose Well
- One (1) Hose Bed Divider
- ROM Satin Finish Roll-Up Doors
- Two (2) Hard Suction Hose Storage Compartments, Rear Access One (1) Each Side
- Ladder Storage Right [...]
RESPONSE ONE #S792
AKRON PRINCEVILLE FIRE PROTECTION DISTRICT, PRINCEVILLE, ILLINOIS- July 9, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on RESPONSE ONE #S792
- Ford F-550 4×4 Super Duty Crew Cab Chassis
- 7.3L Power Stroke V8 Gas Engine
- TorqShift 10-Speed Automatic Transmission
- n-Fab Black Cab Steps
- Buckstop Bumper w/ Brush Guard
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Four (4) Person Cab
- Back-Up Cameras w/ Ford Dash Mounted Display
- ROM Painted Roll-Up Doors
- Two (2 ) 500# Roll-Out Trays, L1 Compartment
- Stokes / Backboard Rack, Transverse through L1/R1 Compartments
- Two (2) Cascade Bottle Storage Transverse L1/R1 Compartments
- PacTrac Vertical Pull-Out Board w/ Two (2) Walk-Away Air Pack Brackets, L2 Compartment
- SpaceSaver 400V Vertical Single Bottle Fill Enclosure, L3 Compartment
- Two (2) 500# Roll-Out Trays, R1 Compartment
- PacTrac Vertical Pull-Out Board w/ Two (2) Walk-Away Air Pack Brackets, R2 Compartment
- PacTrac on Upper Rear Wall, R3 Compartment
- Cribbing Containment Door, R3 Compartment Lower
- One (1) 500# Roll-Out Tray w/ mounted Zico QM-MEH Rotary Tool Holder, Rear Compartment
- Three (3) Single Bottle Wheel Well Storage Compartments, One (1) Left Side [...]
2000 GALLON HAWK TANKER #2539
MAURY COUNTY FIRE DEPARTMENT - COLUMBIA, TENNESSEE- July 9, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 2000 GALLON HAWK TANKER #2539
- Freightliner M2 112 2-Door Chassis
- Cummins L9 450 HP Diesel Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Aluminum Body and Subframe
- ROM Satin Finish Roll-Up Doors
- Waterous CXVPA 750 GPM PTO Pump
- 2,000 Gallon Poly Wetside Tank
- Two (2) 4½” Inlets, One (1) Each Left and Right Side
- Three (3) 2½” Discharges, Two (2) Left Side and One (1) Right Side
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- One (1) 2½” Gated Intake, Left Side
- Two (2) 1½” Mattydale Preconnects
- Two (2) 4” Tank Fills, Rear
- Newton 10” Electric Swivel Dump w/ 36” Manual Extension
- 3” Deck Gun Piping w/ 18” TFT Extend-A-Gun
- Progressive Dynamics Battery Charger w/ Blue Sea Sure Eject Inlet
- Whelen LED Warning Light Package
- Whelen TAL85 LED Traffic Advisor
- Whelen Electronic Siren w/ 100-watt Speaker
- Federal Q2B Siren
- Whelen LED Body Scene Light Package
- Three (3) FireTech HiViz LED Scene Light Bars Cab Roof Mounted [...]
3,000-GALLON TANKER #2561
COLCHESTER FIRE PROTECTION DISTRICT - COLCHESTER, ILLINOIS- June 5, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 3,000-GALLON TANKER #2561
- Freightliner M2 112 2-Door Tandem Chassis
- 450 HP Cummins L9 Diesel Engine
- Allison 3000 EVS Automatic Transmission
- Two (2) Person Cab
- Heavy-Duty Stainless Steel Body and Subframe
- Stainless-Steel Intermediate Pump Module
- Waterous 1250 gpm PTO Pump
- Trident Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Each Side w/ Akron 7983 Butterfly Valve Left Side
- One (1) 2½” Gated Intake Left Side
- One (1) 2½” FirePrograms Tank Fill, Rear
- Two (2) 2½” Discharges Left Side
- One (1) 2½” Discharge Right Side
- One (1) 3” Discharge Right Side adapted to 5” Storz
- Akron 3423 Deck Gun w/ TFT Extend-A-Gun, Hosebed Dunnage
- Mattydale Preconnect Module, One (1) 1½” | One (1) 2½” | One (1) Deadlay
- 3,000-Gallon Poly Tank
- Two (2) 10’ x 6” Hard Suction Gutters, Left Side with Pike Poles and Attic Ladder Bracket
- Ladder Brackets Right Side
- Two (2) 3,000-Gallon Folding Tanks, One Each [...]
1500 GPM REAR MOUNT PUMPER #2518
OHIO FIRE PROTECTION DISTRICT - OHIO, ILLINOIS- May 29, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM REAR MOUNT PUMPER #2518
- Spartan FC-94 LTD 10” Raised Roof Chassis
- Cummins 450 HP L9 Engine
- Allison 3000 EVS Automatic Transmission
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Two (2) Person Cab
- Transverse Storage Chassis Compartment
- Stainless-Steel Rear Mount Pump Module
- Waterous S100C20 1500 GPM Rear Mount Pump
- Trident Automatic Air Prime System
- FRC Pump Boss Pressure Governor & Monitoring System
- Two (2) 6” Intakes, One (1) Rear, One (1) L3 Compartment
- One (1) 6” Front Intake with Elkhart Elbow
- One (1) 2½” Gated Intake, Rear
- Three (3) 2½” Discharges, Rear
- One (1) 3” Discharge, Rear Adapted to 5” Storz
- Two (2) 1½” and One (1) 2½” Cartridge Lay Preconnects
- 1000 Gallon Poly Tank
- ROM Painted Roll-Up Doors
- Three (3) Walk Away Air Pak Brackets, L3 Compartment
- One (1) Triple Wheel Well Air Bottle Compartment, Left Side Ahead
- Hose Bed w/ One (1) Divider, Hypalon Cover
- Ladder Storage w/ Pike Pole Storage, Rear Access Right Side Vertical
- Two [...]
1500 GPM TOP CONTROL PUMPER #2533
GALESBURG FIRE DEPARTMENT - GALESBURG, ILLINOIS- May 29, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 1500 GPM TOP CONTROL PUMPER #2533
- Spartan FC-94 MFD 10” Raised Roof
- Cummins L9 450 HP Diesel Engine
- Allison 3000 EVS Transmission
- Heavy Duty Stainless-Steel Body and Subframe
- Four (4) Person Cab
- ROM Painted Roll-Up Doors
- Hale DSD 1500 gpm Pump
- Trident Air Primer, Two (2) Location
- 750 Gallon Poly Tank
- Stainless-Steel Top Mount Pump Module w/ 22” Midship Walkway
- Two (2) 6” Intakes, One Each Side, Left and Right
- One (1) 5” Front Intake
- One (1) 2½” Gated Intake, Left Side
- Three (3) 2½” Discharges, Two (2) Left and One (1) Right Side
- One (1) 3” Discharge Reduced to 2½” MNST, Rear
- One (1) 3” Discharge Adapted to 5” Storz, Right Side
- Two (2) 1½” Mattydale Preconnects Deep Cut
- TFT Crossfire XFC-42 Deck Gun with 18” Extend-A-Gun
- Two (2) Free Floating Hose Wells, One Each Left and Right Side Running Boards
- Two (2) Triple Air Bottle Wheel Well Compartments, One (1) Each Side Ahead
- One (1) Fire Extinguisher Wheel [...]
12’ RESPONSE ONE #SK898
PESOTUM FIRE PROTECTION DISTRICT - PESOTUM, ILLINOIS- May 29, 2024
- Not categorized
- Posted by R_Admin
- Comments Off on 12’ RESPONSE ONE #SK898
- Ford F-550 Chassis
- 6.7L V8 Diesel Engine
- TorqShift 10-Speed Transmission
- Heavy Duty Stainless-Steel Body and Sub-Frame
- Five (5) Person Cab
- Ranch Hand Black Brush Guard with Receiver and Winch Wiring
- Warn Zeon 10 Multi-Mount Winch
- n-FAB Podium Nerf Bars
- ROM Painted Roll Up Doors
- Darley 1½AGE 21H Gas Pump with Honda GX630 Engine Rear
- One (1) 2½” Rear Intake
- One (1) 2½” Rear Discharge
- One (1) 1½” Rear Discharge
- Akron 3463 FireFox Front Bumper Turret with Cab Joystick Control
- Booster Reel 100’ of 1” Above Pump
- Around The Pump Foam Eductor with 10G tank
- 300G Skid Tank
- Two (2) Single Bottle Wheel Well Compartments, Right Side
- Two (2) Backboard and Pike Pole Transverse Rack L1/R1 Compartments
- One (1) 500# Roll Out Tray with shelf L1 Compartment
- One (1) 500# Roll Out Tray R1 Compartment
- Hinged Pac Trac Tool Board L2 Compartment
- Two (2) Walk Away Air Pack Brackets R2 Compartment
- Two (2) Fire [...]
