TOP CONTROL PUMPER #2489

HENRY FIRE PROTECTION DISTRICT - HENRY, ILLINOIS
FEATURES:
  • Spartan Metro Star EMFD 10” Raised Roof Chassis
  • Cummins L9 450 HP Diesel Engine
  • Allison 3000 EVS Automatic Transmission
  • Heavy Duty Stainless-Steel Body and Sub-Frame
  • Five (5) Person Cab
  • One (1) Center Console with Switches
  • 6” Front Bumper Extension
  • Satin Finish ROM Roll-Up Doors
  • 1000-Gallon Poly Tank
  • 20-Gallon Foam Tank for Waterous Aquis 1.5 Foam System
  • Stainless-Steel Top Control Pump Module
  • Hale QMAX 200 Single Stage Split-Shaft 2000 GPM Pump
  • Trident Air Prime System with Additional Primer
  • FRC Pump Boss Pressure Governor & Monitoring System
  • Hose Bed with Three (3) 5” LED Lights
  • Two (2) 6” Intakes with Akron Hand Wheel Butterfly Valves, One (1) Left, One (1) Right
  • One (1) 2½” Gated Intake, Left Side
  • One (1) 5” Rear Intake
  • Two (2) 1½” Cartridge Lay Foam Capable Preconnects
  • One (1) 2½” Discharge, Left Side
  • One (1) 2½” Discharge, Right Side
  • One (1) 4” Discharge, Left Side Adapted to 5” Storz
  • One (1) 4” Discharge, Right Side, Adapted to 5” Storz
  • Akron 3423 Deck Gun with 18” Task Force Tips Extend-A-Gun
  • One (1) 10” Newton Stainless-Steel Dump with Electric Valve, Rear
  • One (1) Zico Hydraulic Ladder Rack, Right Side
  • One (1) Fire Extinguisher Storage Compartment, Left Side Ahead of Wheel Well
  • Two (2) Triple Air Bottle Compartments, Right Side
  • PacTrac Upper Rear Wall of L1, L3, R1, R3 Compartments
  • Hinged PacTrac Tool Board, L2 Compartment
  • Five (5) 500# Roll-Out Trays, L1, L3, R1, R3, Rear Compartments
  • One (1) Kussmaul 120V 20A Shoreline Connection, Cab Left Side
  • Whelen Warning Light Package
  • Whelen and FireTech Scene Lights
  • Akron Telescopic Scene Lights, One (1) Each Side
  • Federal Q2B Siren
  • inView 360° Backup Camera System, One (1) Camera Each Side and Rear, Displays in Cab and at Pump Panel
  • One (1) 120V Power Strip in Each Compartment
  • Aluminum Rub Rails with LED Warning Lights & LED Ground Lighting
  • Diamond Grade Chevron Striping
  • 10’ 6” Overall height
  • 34’ 7” Overall length
  • 233” Wheelbase
  • 173” Cab to Axle
  • 20,000 FAWR
  • 27,000 RAWR
  • 47,000 GVWR
Year: 2023
Make: Alexis Fire Equipment
Model: Pumper
Chassis: Custom
Body Style: Top Control Pumper
Pump Size: 2000
Tank Size: 1000
Feature: 20-Gallon Foam Tank
Exterior Color: Red
New Delivery: New Delivery
