3000-GALLON PUMPER/TANKER #2283

PROSPECT HEIGHTS FIRE PROTECTION DISTRICT - PROSPECT HEIGHTS, ILLINOIS
  • Freightliner M2 106 2-Door Tandem Chassis
  • Cummins ISL, 350-HP Diesel Engine
  • Allison 3000 EVS Automatic Transmission
  • Heavy Duty Stainless Steel Body and Sub frame
  • ROM Roll Up Doors
  • 3000-Gallon Wet Side Poly Tank
  • One (1) 2 ½” Fireman’s Friend Tank fill, rear
  • One (1) Newton 10” square manual swivel tank dump with 36” extension, rear
  • Darley PSM, 1250-GPM Pump
  • Pump Operator’s panel under tank on left side
  • Three (3) 2 ½” Discharges, two (2) left side and one (1) right side
  • One (1) 3” Discharge, right side
  • Two (2) 1 ½” and one (1) 2 ½” Mattydale Preconnects
  • One (1) 2 ½” Gated Suction, left side
  • Folding Tank rack storage, top of compartments left side
  • Ladder & Pike pole storage , top of compartments right side
  • Suction hose storage, hose bed
  • Four (4) Air pack brackets, two (2) each side rear compartment
  • Floor mounted console for Emergency switches, cab
  • Air coupling for external compressor
  • Code 3 Electronic Siren with 100-watt Code 3 speaker
  • Code 3 & Whelen Pioneer Plus LED Scene Light Packages
  • Code 3 LED Warning Light Package
  • Diamond Grade Chevron pattern striping, rear
  • 9’ 11” Overall height
  • 33’ 2” Overall length
  • 248” Wheelbase
  • 182.45” Cab to Axle
  • 16,000 FAWR
  • 40,000 RAWR
  • 56,000 GVWR
Year: 2017
Make: Alexis Fire Equipment
Model: Tanker
Chassis: Commercial
Body Style: Tanker
Pump Size: 1250
Tank Size: 3000
Exterior Color: Red
New Delivery: New Delivery
