1800 GALLON SUPER TANKER #2486

IBERIA JOINT FIRE DISTRICT - GALION, OHIO
FEATURES:
  • Spartan FC-94 MFD 10” Raised Roof Chassis
  • Six (6) Person Cab
  • Cummins L9 450 HP Diesel Engine
  • Allison 3000 EVS Automatic Transmission
  • Heavy-Duty 304 Stainless-Steel Body and Sub-Frame
  • ROM Roll Up Doors, Satin Finish with Pull Straps
  • 1800 Gallon Poly Tank with Painted Aluminum Bolt-On Side Panels
  • Stainless-Steel Intermediate Pump Module with Heat Pan
  • Waterous CX Single Stage Split-Shaft 1250 GPM Pump
  • Trident Air Prime System
  • FRC Pump Boss Pressure Governor & Monitoring System
  • 24” Front Bumper Extension with Two (2) 1½” Preconnects, Two (2) Full Width Hose Trays and Hypalon Cover
  • Two (2) 6” Intakes, One (1) Each Side, One (1) Akron 7983 Butterfly Intake Valve Left Side
  • One (1) 2½” Gated Intake, Left Side
  • One (1) 4” Tank Fill Adapted to 5” Storz, Rear
  • Two (2) 2½” Discharges, Left Side
  • One (1) 2½” Discharge, Right Side
  • One (1) 3” Discharge Adapted to 4” Storz, Right Side
  • One (1) 2½” Discharge, Rear
  • One (1) 3” Deck Gun Discharge
  • Two (2) 1½”, One Deadlay Mattydale Preconnects
  • One (1) Newton 10” Rear Stainless-Steel Manual Swivel Dump
  • Hose Bed with Two (2) Dividers and Bulkhead LED lighting
  • Ladder Storage Capacity: 24’ 2 Section Ground Ladder, 14’ Roof Ladder with Hooks, 10’ Attic Ladder, Two (2) Pike Pole Tubes, Rear Access
  • One (1) Zico Hydraulic 2,100 Gallon Folding Tank Rack, Right Side
  • One (1) Fire Extinguisher Storage Compartment, Left Side Ahead of Rear Wheel Well
  • One (1) Triple Air Bottle Storage Compartment, Right Side Ahead of Rear Wheel Well
  • One (1) Dual Air Bottle Storage Compartment, Right Side Behind Rear Wheel Well
  • One (1) 250# Roll Out Tray, L1 Compartment
  • Two (2) Pac Trac Tool Boards, Upper L1 Compartment, Rear L2 Compartment
  • One (1) Hinged Pac Trac Tool Board, L2 Compartment
  • One (1) Cribbing Containment Door, L3 Compartment
  • Two (2) 500# Roll Out Trays, One (1) Each R1, R2 Compartments
  • Three (3) Rear Folding Steps
  • Progressive Dynamics Battery Charger with Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection, Above Left Front Wheel Well
  • Federal Q2B Siren, Pedestal Mounted Front Bumper
  • Two (2) Air Horns, Recess Mounted Front Bumper
  • Whelen Electric Siren & 100W Speaker
  • Whelen LED Warning Light Package
  • 360º Firetech HiViz Scene Lighting
  • One (1) Rear Mounted Backup Camera
  • 10’ Overall height
  • 32’ 9” Overall length
  • 194” Wheelbase
  • 140” Cab to Axle
  • 21,500 FAWR
  • 31,500 RAWR
  • 53,000 GVWR
Year: 2023
Make: Alexis Fire Equipment
Model: Pumper/Tanker
Chassis: Custom
Body Style: Tanker
Pump Size: 1250
Tank Size: 1800
Feature: Hydraulic Folding Tank Brackets
Exterior Color: Red
New Delivery: New Delivery
Program Vehicle: Super Tanker
