Delivered Apparatus

FEATURES:

• Freightliner M2 106 Chassis Crew Cab Chassis
• Cummins 360 HP L9 Engine
• Allison 3000 EVS Automatic Transmission
• Heavy Duty Aluminum Body and Sub-Frame
• Five (5) Person Cab
• Stainless-Steel Top Mount Pump Module with 22” Midship Walkway
• Hale DSD150 Single Stage Split-Shaft 1500 GPM Pump
• Trident Air Prime System
• FRC Pump Boss Pressure Governor & Monitoring System
• Two (2) 6” Intakes, One (1) Each Side
• One (1) 2½” Gated Intake, Left Side
• One (1) 2½” Tank Fill Adapted to 3” FirePrograms Valve
• Two (2) 2½” Discharges, Left Side
• One (1) 2½” Discharge, Right Side
• One (1) 3” Discharge, Right Side Adapted to 5” Storz
• One (1) 3” Discharge, Rear Adapted to 2½” NST
• Two (2) 1½” Mattydale Preconnects
• One (1) Booster Reel 150’ of 1”, Rear
• 1000-Gallon Poly Tank
• AFE Stainless-Steel Top Access Ladder
• Hose Bed with One (1) Divider, Three (3) LED Lights, Hypalon Cover
• Ladder Storage Capacity: One (1) 24’ 2 Section Ladder, One (1) 14’ Roof Ladder, One (1) 10’ Attic Ladder, Rear Through Tank
• Two (2) 10’ x 6” Hard Suction Hoses, Rear Through Tank
• Three (3) Dual Wheel Well Air Bottle Compartments, One (1) Left, Two Right
• One (1) Center Console with Switches
• Progressive Dynamics Battery Charger with Viair Compressor Kussmaul 20 Amp Super Auto-Eject 120V Shoreline Connection, Under Cartridge Lay
• Whelen LED Warning Light Package
• Whelen Scene Lights, One (1) Each Side, Two (2) Rear
• Whelen Electric Siren & 100W Speaker
• 9’11” Overall height
• 34’ Overall length
• 258” Wheelbase
• 145.2” Cab to Axle
• 16,00 FAWR
• 30,000 RAWR
• 46,000 GVWR
