Wapello Fire And Rescue
Wapello, Iowa
Technical Specs
• Peterbilt 340, 2-Door
Chassis
• Caterpillar C7, 330-HP Diesel Engine
• Allison 3000 EVS, Automatic Transmission
• Heavy Duty 3/16" Aluminum Body
• Ramsey 9000-lb. Winch with Reese type front and
rear receivers
• Two (2) Hitch receiver winch points, one (1)
each side
• Top Access Ladder mounted on the rear
• Command Desk/Map storage Cabinet, right side
interior
• Drop Down Squad Bench with four (4) walk-away
brackets, internal squad area
• Two (2) interior compartments with Roll-up Doors,
rear wall crew area
• Two (2) Side Squad body Windows, one (1) each
side
• One (1) Electrically activated side Step
• Oil Dry Hopper in the left rear wheel well
• Two (2) Watertight Upper Storage Compartments
with lift up doors on the roof
• ROM Roll Up Doors
• One (1) Stokes basket/Back Board Rack with three
(3) back boards and one (1) stokes basket capacity
• Two (2) Hannay Dual Hydraulic Hose Reels, rear
compartment
• Kussmaul Pump-Plus 1200 air compressor/battery
charger
• Kussmaul Super Auto Eject 120-volt Shoreline
• One (1) Hannay 120-volt Electric Cord Reel
• Four (4) Whelen large Scene lights, two (2) each
side
• 25,000-Watt, 120-volt PTO Driven Generator
• Night Scan Powerlite Light Tower with Dual Tilt
• Two (2) Grover Hi/Low Alternating Air Horns
• Whelen 200-watt Siren
• Whelen Warning Light Package
• 11' 4" Overall height
• 28' 9" Overall length
• 209" Wheelbase
• 139.2" Cab to Axle
• 12,000 FAWR
• 23,000 RAWR
• 35,000 GVWR
|
