TYPE III AMBULANCE #A231
MASON COUNTY AMBULANCE
HAVAVA, ILLINOIS

Technical Specs
• Chassis: 2013, GM, G3500
• Engine: 6.6 Duramax 6600 Turbo Diesel
• Transmission: 6-speed automatic
• Brakes: 4-Wheel Anti Lock, 4-wheel disc
• Wheel Simulators: Phoenix installed over steel wheels
• Cab Extension: 6 inch allows full OEM seat travel
• Warning Lights: LED, Whelen 900 series
• Scene Lights: Whelen Halogen 900 series
• Circuit Board: RMR rail system
• Tail Lights: Whelen LED, 900 series
• Light Bar: Total (7) 900 LED across front of Module
• Power Locks: Rear and Side Access Doors
• AEV Extruded Aluminum Body : 145 x 92 x 68" Interior Head Room
• Compartment type: Aluminum
• Size/Headroom: 68" HR
• Inverter: Vanner 20-1050 Full Mod
• Shoreline: 20 amp, Twisloc
• Siren: Whelen 295SLSA1, Standard G3/4500
• Attendant Seat: Wise, Hi-back, 3-Point Seatbelt
• patient lights: Kinequip , (3) streetside, (3) curbside
• Wheelbase: 139"
• FAWR: 4,600
• RAWR: 8,600
• GVWR: 12,300

Download Spec Sheet »






Alexis Fire Equipment would like to thank the members of the
MASON COUNTY AMBULANCE for their business.
