Bethany Fire Protection District
Bethany, Illinois
Technical Specs
•International 4400 4-Door Chassis
• International GDT330. 330-HP Gasoline Engine
• Allison 3000 EV Automatic Transmission
• Heavy Duty 3/16” Aluminum Body
• UPF1000-Gallon T-Type Poly Tank
• Hale QMID125, 1250-GPM Pump
• Four (4) 2 ½” Discharges, Two (2) left side, one (1) right side and one (1) rear
• One (1) 2 ½” Gated Suction, left side
• One (1) 5” suction, front and one (1) 3” Discharge for Deck Gun, top
• One (1) Elkhart Portable Deck Gun with 1000-GPM flow
• Two (2) 1 ½” Cartridge Lay Preconnects with white covers
• ROM Roll Up Doors
• Zico Hydraulic ladder rack with attic ladder and pike pole brackets, right side
• One (1) Newton Manual Tank dump with 36” Extension, rear
• One (1) hard suction hose storage in rear compartment and one (1) on ladder rack
• Manual Battery recharge receptacle, left side
• Two (2) Unity Deck lights, rear
• One (1) Manual 120-volt Shoreline
• Onan 8-kW Hydraulically driven Generator
• Two (2) Extenda-Light 120-volt, 500-watt Telescopic Flood lights, one (1) each side
• Federal Electronic Siren with 100-watt Federal speaker
• Power Arc Warning Light Package
• 10’ Overall height
• 34’ 7” Overall length
• 258” Wheelbase
• 147” Cab to Axle
• 12,000 FAWR
• 23,360 RAWR
• 35,360 GVWR
|
