Abingdon Fire Protection District
Berwick Unit
Abingdon, Illinois
Technical Specs
• Ford F-750 2-Door Chassis
• Cummins ISB325, 325-HP Diesel Engine
• Allison 3500EV Automatic Transmission
• Heavy Duty 3/16” Aluminum Body
• A.P.R. Plastics 1500-Gallon Wetside Poly Tank
• Hale PSD75, 750-GPM Pump
• Left Side Pump control panel
• Three (3) 2 ½” Discharges, one (1) each side and one (1) rear
• One 2 ½” Gated Suction, left side
• Two (2) Mattydale 1 ½” Preconnects with capacity for 200-ft of 1 ¾” hose each
• ROM Roll Up Doors
• One (1) E J Metals 10” round air operated Tank dump with manual 22” extension, rear
• Manual Battery Recharge receptacle at the driver’s entrance
• Air coupling for external compressor at the driver’s entrance
• One (1) Whelen Large Scene light, rear
• Two (2) Unity Deck Lights, rear
• Ladder brackets, right side
• One (1) Pike pole tube, right side compartment top
• Suction hose enclosed storage for two (2) 10-ft. hoses in hose bed
• Poly Folding Tank storage compartment integral with tank, left side with rear access
• Federal Electronic Siren with 100-watt Federal speaker
• Code-3 Upper Warning Light Package
• PowerArc Lower Warning Light Package
• 8’ 4” Overall height
• 27’ 4” Overall length
• 212” Wheelbase
• 137.7 Cab to Axle
• 13,200 FAWR
• 23,000 RAWR
• 33,000 GVWR
|
